Production processing of aluminum tread plate

China Supplier:Signi Aluminium
Author :frank   Time:2022-03-22
Guide :When an aluminum processing plant processes aluminum and aluminum alloys into sheet and strip products, the entire processing process is called one-time processing.

When an aluminum processing plant processes aluminum and aluminum alloys into sheet and strip products, the entire processing process is called one-time processing. These processed sheet and strip products are made into semi-finished products, and if they are further processed, they are called deep processing. Such as processed processing of aluminum tread plate and so on.

Production processing of aluminum tread plate

The development of deep processing is the main way to save energy, save metals, reduce transportation, rationally use resources, and increase economic benefits. At present, foreign countries pay more attention to deep processing. Many aluminum processing plants have deep processing workshops, and their products account for about one processing time. about 30% of the product.

The embossing aluminum tread plate it produces is mainly used for decoration and packaging.

The characteristics of this machine train are: the quality of the embossed board produced is relatively stable, the entire production process of the embossed board is relatively simple, the speed and efficiency of the production of the embossed board are relatively high, and the output is relatively high. In addition to the press, there are other auxiliary machines. This machine adopts the continuous pressing of reels to produce embossed sheets. It includes

Uncoiler, Feeding Roller, Roller Straightener, Embossing Machine, Edge Trimming Machine, Slitting Machine, Coiler, etc.

Production process: uncoiling, roll straightening, embossing, trimming, slitting, coiling

The quality of the aluminum tread plate is good, the surface is bright, the pattern is clear, and the plate surface is flat.

Alloy 1060, 1100, 1200, 3003, 3105, 5005, 5052, 5251, 5754, 5454, 5154, 5083, 5086  6061, 6082
Temper H114, H224, H12, H14, H16, H18, H32, H34, H36, H38, T4, T6, F
Surface Bright finish, Mill finish
Bar Difference 1 bar (Diamond), 2 bar, 3 bar, 5 bar
Available Dimension
  Mill finish Surface Bright finish Surface
Thickness  (mm) 1.00---6.50mm 1.20---6.50mm
Pattern height Sheet Thickness from 1.0mm to 2.0mm,  bar height: 0.50mm Sheet Thickness from 1.0mm to 2.0mm,  bar height: 0.50mm
Sheet Thickness from 1.0mm to 2.0mm,  bar height: 1.00mm Sheet Thickness from 1.0mm to 2.0mm,  bar height: 1.00mm
Sheet Thickness above 2.0mm,  bar height: 1.50mm Sheet Thickness above 2.0mm,  bar height: 1.50mm
Width (mm) Maximum 1500mm Maximum 1650mm
Length (mm) Maximum 6000mm Maximum 6000mm
Paper interleaves On request for selected On request for selected
Normal size 1200×2400mm, 1219×2438mm,  1219×3048mm 1200×2400mm, 1219×2438mm,  1219×3048mm
